COLLAR:
1/2" O.D. x 3/8" I.D. x 24" Length Polyvinyl Tubing, UV Stabilized
FITTINGS:
Wire rope clips type-A malleable iron copper oval & stop compression sleeves
|
COMPRESSION SPRINGS:
Zinc Coated: Free Length: 12:00 Inch.
Solid Length; 8.00"; Total Coils: 56
WIRELESS GUY LINE:
5/8" OD x 3/8 ID x 60" Length; Polyvinyl Tubing White; UV Stabilized; 2550 PSI Tensile Strength 350% Ultimate Elongation: 230 PSI Tear Strength Brittleness Temp. -36 Degrees C.
ASTM: D412, D1004, D746
STEEL WIRE ROPE:
1/8" O.D., 7X19 Galvanized Aircraft Cable: 2000lb. NBS
UNDERGOUND FLEXIBLE-ANCHOR:
Include, factory installed material; recycled polyethylene size 1"x2"x15"; shear strength:2150 PSI Compressive strength 3040 PSI |
| FEATURES |
SHOCK ABSORBING GUY LINE
Eliminates sudden pressure caused by tree movement from being placed on anchor. The tree will not pull out the anchor.
FREEDOM OF MOVEMENT
Tree will sway independently of anchor constraints. Anchor will not cause damage to three by way of restriction.
A SIMPLE ANCHOR:
Deadman, concrete, 2 by 4, 30" pipe, not required. No-Shock, No-Pressure, Means less anchor
SELF ADJUSTING:
Compressions springs inside pvc tubing constantly react to motion thus maintain taughtness in the guilde lines
CONVENIENT:
Factory assembled unites including anchor are easy to install and are adjustable from 6 to 16ft. |
|
